SpeedyBee F7V2 Specifications
MCU: STM32F722
IMU: MPU6000
USB: Type-C
Baro: BMP280 (I2C)
OSD: BetaFlight OSD w/ AT7456E chip
BLE: Support, used for Flight Controller configuration
WiFi: Support, used for data transfer, e.g firmware
flashing, and Blackbox analysis.
DJI Air Unit slot: A full DJI Air Unit JST slot onboard
BlackBox: 16MB onboard dataflash
Current Sensor: 1 : 10 (Scale 168)
BetaFlight Camera Control Pad: Yes
Power input: 3S - 6S Lipo
5V power output: 7 * 5V output, 6 pads and a BZ+ pad used for Buzzer, the maximum load current is 2.5A. 9V * 1,
the maximum load current is 2.5A.
9V power output: 2 * 9V output, 1 pads and another one used for DJI slot
4.5V power output: 1 * 4.5V output pad
3.3V power output: 1 * 3.3V output pad, the maximum load current is 500mA.
ESC signal: M1 - M4
UART: Full UART * 5(UART1, UART2, UART3, UART5, UART6)
ESC Telemetry UART: UART4 RX
I2C: Used for external Magnetometer, Sonar, etc.
LED pin: Used for WS2812 LED
Buzzer: BZ+ and BZ- pad used for 5V Buzzer
Boot button: Used to easy enter DFU mode
RSSI input: RSSI input solder pad
SmartPort: Use any TX pad of UART for the SmartPort feature.
Support Flight Controller Firmware: BetaFlight(Default), EMUFlight
Target name: SPEEDYBEEF7V2
Mounting: 30.5 x 30.5mm, 4mm hole size
Dimension: 41 x 38 x 6.9mm
Weight: 9g
SpeedyBee BLHeli32 45A 4 in 1 ESC Specifications
Firmware: BLHeli32 SpeedyBee 4in1
MCU: STM32F051
Continuous Current: 45A * 4
Burst Current: 55A(10S)
ESC Protocol: DSHOT300/600/1200
Power input: 3S - 6S LiPo
Power output: VBAT
Current Sensor: Support (Scale 168)
ESC Telemetry: Support
Mounting: 30.5 x 30.5mm, 4mm hole size
Dimension: 41 * 45 * 6.5mm
Weight: 12.5g
