Summary
The GEPRC team has redesigned the Vapor series for optimal compatibility with the DJI O4 Air Unit Pro VTX.
New aluminum lens components and shock-absorbing silicone reduce vibrations, while the sharp new side panels give it a bold, mech-inspired look. The DJI O4 Air Unit Pro’s larger CMOS sensor enhances image detail and sensitivity, and the GEPRC-tuned PID settings ensure a smooth and immersive flight experience.
Available in two models, Wide X and DC, to suit different flight needs.
Feature
- DJI O4 Air Unit Pro features a powerful CMOS sensor for improved image clarity and enhanced light sensitivity.
- CNC aluminum lens housing for a durable, bold design.
- GEPRC SPEEDX2 E-series motors for smooth, powerful performance.
- Front lip design provides extra lens protection for confident flying.
- Wider 5mm carbon fiber arms for increased durability and a sleek build.
Specifications (X5)
- Model: Vapor-X5 O4 Pro
- Frame: GEP-Vapor-X5 O4 Pro frame
- Wheelbase: 230 mm
- Top Plate: 2.0 mm
- Middle Plate: 2.0 mm
- Bottom Plate: 2.5 mm
- Arm Thickness: 5.0 mm
- FC: GEP-F722-HD v2
- MCU: STM32F722
- Gyro: ICM42688-P(SPI)
- Barometer: YES
- OSD: Betaflight OSD w/AT7456E
- ESC: TAKER H60_BLS 60A 4IN1 ESC
- VTX: DJI O4 Air Unit Por
- Camera: O4 Pro Camera
- Antenna: O4 Pro original antenna
- Connector: XT60
- Optional GPS: GEP-M10 GPS
- 5-inch Motor: GEPRC SPEEDX2 2207E 1960 KV
- 5-inch Propeller: GEMFAN 5136
- Vapor-X5 O4 PNP Version Weight: 409g±5g
- Receiver: PNP/GEPRC ELRS24/TBS Nano RX
- Recommended Battery: 6S LiPo1300mAh – 1800mAh
- Flight Time: 14-19min
Specifications (D5)
- Model: Vapor-D5 O4 Pro
- Frame: GEP-Vapor-D5 O4 Pro frame
- Wheelbase: 230 mm
- Top Plate: 2.0 mm
- Middle Plate: 2.0 mm
- Bottom Plate: 2.5 mm
- Arm Thickness: 5.0 mm
- FC: GEP-F722-HD v2
- MCU: STM32F722
- Gyro: ICM42688-P(SPI)
- Barometer: YES
- OSD: Betaflight OSD w/AT7456E
- ESC: TAKER H60_BLS 60A 4IN1 ESC
- VTX: DJI O4 Air Unit Por
- Camera: O4 Pro Camera
- Antenna: O4 Pro original antenna
- Connector: XT60
- Optional GPS: GEP-M10 GPS
- 5-inch Motor: GEPRC SPEEDX2 2207E 1960 KV
- 5-inch Propeller: GEMFAN 5136
- Vapor-X5 O4 Pro PNP Version Weight: 428 g±5g
- Receiver: PNP/GEPRC ELRS24/TBS Nano RX
- Recommended Battery: 6S LiPo1300mAh – 1800mAh
- Flight Time: 14-19 min
Includes
1 x Vapor-X5/D5 O4 Pro
2 x GEMFAN 5136
2 x Battery anti-slip pads
1 x Spare screw pack
1 x Vapor side panel
2 x M20*250mm battery straps
1 x L-shaped screwdriver 1.5mm
1 x L-shaped screwdriver 2.0mm
1 x GoPro mount
The spare screws include
6 x M3*10mm round head screws
6 x M3*8mm round head screws
2 x M3*6mm flat head screws
1 x M5*28mm thin head screw
1 x M5 flange nut
4 x M3 rivet nuts
